Cadre
Aluminum, 9x135mm QR, 26"
Fourche
RST First Coil w/Soft Spring and Preload, 100mm, 9X100 QR
Manette Arrière
Shimano SL-RV200-6R, 6sp, gripshift
Dérailleur arrière
Shimano TZ-500, 6sp, Direct mount
Pédalier
Alloy 3pc, 140mm, 28T Narrow Wide
Jeu de pédalier
Sealed bearing, ST 68mm
Cassette
Shimano MF-TZ500-6, 14-28T, 6sp, Freewheel
Chaîne
KMC Z6
Frein avant
C-Star, Resin Pads, Mechanical Disc
Disque avant
160mm, 6-Bolt
Frein arrière
C-Star, Resin Pads, Mechanical Disc
Disque arrière
160mm, 6-Bolt
Leviers de Frein
C-Star Alloy Jr. Levers w/reach adjust
Guidon
Alloy Jr. Riser, 720mm, 30mm Rise
Potence
Alloy 40mm Length, 31.8mm Clamp
Tige de Selle
Norco Alloy 27.2mm, 250mm length
Jeu de direction
External Cup Ball Bearing, 1-1/8" EC 34
Selle
Norco Jr XC, Steel Rail
Poignées/guidoline
Norco Youth, 115mm Length
Pédales
Jr. MTB Flat, 9/16"
Collier de tige de selle
Norco Alloy Bolted, 31.8mm ID
Moyeu avant
Formula DC-1420 , 9x100mm QR, 28h, 6-bolt
Moyeu arrière
Formula DC-31R-7S, 9x100mm QR, Freewheel, 28h, 6-bolt
Jantes
Aluminum DW, 28h, 26" MTB
